A small footprint with GPU capabilities. Versatile and easily configurable, the AVC0500 boasts advanced thermal management in a sealed, submersible chassis for rugged compute performance. This embedded computer system has a flexible I/O expansion options, while following leading-edge CPU and GPU roadmaps to ensure access to the latest, most powerful silicon chipsets and processors. The integrated DC power supply is designed for low voltage noisy vehicular applications.
AVC0500 Features
- IP67 water and dust sealed
- IPMI intelligent management control
- Liquid cooling
- Supports multiple FH & LP PCIe cards
- 18-36 VDC automotive power
- U.2 NVMe SSD storage
Mechanical
| Height | 3.8” (9.6 cm) |
| Width | 17.4” (44.2 cm) |
| Depth | 13” (33 cm) |
| Weight | 40 lbs (18.1 kg) |
| Power | 75-900W with select configurations; CPU/GPU dependent |
Mounting
| Option 1: | Tray |
| Option 2: | Bulkhead |
| Option 3: | Rack |
Power Supply
| 18–36VDC |
CPU Architecture
| AMD EPYC 7003 family |
Internal Bay
| Dual U.2 NVMe SSD storage, up to 15TB |
Cooling
| Liquid cooling for extreme thermal performance when paired with optional customer supplied or Crystal Group cooling loop |
Environmental Standards
| Testing in Progress | |
| MIL-STD-810, Operational Temperature | -30°C to +55°C |
| MIL-STD-810, Storage, Method 501, Procedure I/II | -30°C to +85°C |
| MIL-STD-810, Humidity, Method 501, Procedure II | 240 hours with humidity kit |
| MIL-STD-810, Humidity, Method 507, Procedure II | 12,500ft operation, 40,000ft transport |
| MIL-STD-810, Vibration, Method 514, Procedure I | 4.63Grms, 5–2,000Hz, 60 min/axis, 3 axis |
| SAE J1455 | Vibration per SAE J1455 for cab mounted components |
Electromagnetic Compatibility Standards
| CISPER 25:2021 | Class 2 |
